Φ10mm Micro 2-2 Phase 5V Stepper Motor Series KC-10BY2510/2520/2530-N

Technical Specification
KC-10BY Series
Precision 10mm Stepper Motor — Optimized for precise integration and durable performance
Motor Type
2-Phase Bipolar Stepper
Step Angle
18°
Rated Voltage
5.0 V DC
Holding Torque
18.0 – 20.0 gf·cm
Frame Diameter
Φ 10.0 mm
Configuration
Direct Drive Shaft
✓ Custom samples: 10-20 days
✓ Bulk order pricing available
✓ ISO 9001, CE & RoHS Compliant
Applications: Precision medical instruments, portable infusion pumps, automated laboratory analyzers, handheld pipettes, micro fluidic control, optical positioning systems, laser equipment calibration, surveillance PTZ cameras, mini smart locks, electronic access control, precision valve actuators, automotive electronic throttles, HUD motorized mirrors, miniature security systems, smart wearable equipment, micro robotics, compact consumer electronics, drone gimbal stabilization, precision instrumentation…
Inquiry Now

KC-10BY Series Stepper Motor Performance Specifications

* Tested at 800 PPS
Model Rated Voltage Resistance Per Phase Current Per Phase Detent Torque Holding Torque
KC-10BY2510-N 5.0 V DC 10 Ω 630 mA 6.0 gf·cm 20.0 gf·cm
KC-10BY2520-N 5.0 V DC 20 Ω 310 mA 6.0 gf·cm 20.0 gf·cm
KC-10BY2530-N 5.0 V DC 40 Ω 150 mA 6.0 gf·cm 18.0 gf·cm

KC-10BY Series Mechanical & Environmental Parameters

Parameter Specification
Step Angle 18°/step
Excitation Mode 2–2 phase excitation
Motor Thickness 15 mm
Insulation Resistance More than 50 MΩ at 300 V DC
Noise Level Less than or equal to 50 dB(A)
Operating Temperature Range 10–50 °C

KC-10BY Series Dimensions & Technical Drawing

Dimensional specifications for system integration | All values in millimeters

KC-10BY stepper motor 2D drawing showing 10mm diameter 15mm thickness outline dimensions.

KC-10BY Series Miniature Stepper Motor Mechanical Installation Dimensions

Custom Motor Performance Advantages

  • Precise motion control: The standard 18° step angle with 2–2 phase excitation ensures accurate positioning for high-accuracy instrumentation.
  • Optimized integration: Featuring a 10 mm diameter and a precise 15 mm thickness, this miniature design facilitates integration into restricted physical spaces.
  • Flexible electrical configurations: Multiple coil resistance options (10 Ω, 20 Ω, and 40 Ω) allow precise matching with different drive current limits from 150 mA to 630 mA.
  • Acoustically optimized operation: Strict control of structural dynamics restricts total operational noise to less than or equal to 50 dB(A).
  • Durable electrical insulation: Heavy-duty coil design withstands up to 300 V DC, maintaining an insulation resistance higher than 50 MΩ for extended service life.
  • B2B custom sample availability: Flexible modification protocols support tailoring voltage, current, shaft profiles, and lead configurations to unique industrial parameters.
