36mm 555 DC Motor with Pinion Gear 12V 7597RPM 24V 6989RPM
Applications: Automated paper shredders, vending machine drive systems, electric lock mechanisms, precision automated office equipment, electric handheld power tools.
Inquiry NowKC-555PH Series DC Motor Performance Data
| Parameter | KC-555PH-4560 (12 V) | KC-555PH-2968 (24 V) |
|---|---|---|
| Rated Voltage | 12 V | 24 V |
| Start Voltage | 0.7 V | 0.9 V |
| No-load Speed | 7597 rpm | 6989 rpm |
| No-load Current | 337 mA | 229 mA |
| Starting Torque | 2.7 kg·cm | 2.8 kg·cm |
| Stall Speed | 7039 rpm | 6055 rpm |
| Stall Current | 1.7 A | 1.8 A |
Mechanical Specifications
| Parameter | Specification Value |
|---|---|
| Motor Diameter | 36 mm |
| Motor Length | 57 mm |
Technical Drawing And Mounting
Engineering Advantages
- Optimized power density: 36 mm diameter frame provides precise torque delivery in restricted spaces.
- Durable construction: Engineering-grade materials ensure stable long-term operation under load.
- Compatible integration: Standardized mounting dimensions and shaft configurations facilitate rapid system assembly.
- Efficient performance: High starting torque capabilities support reliable startup for demanding mechanical loads.
- Precise speed control: Optimized winding configurations result in consistent rpm output across voltage variances.
